Description
ZOOM H4n Pro merupakan Handy Recorder yang sesuai untuk produksi film, podcasting, field interview, sound design, musician, dan voice-over. H4n Pro merupakan 2-channel (in stereo mode) portable recording device dengan antarmuka USB yang sesuai dengan telapak tangan Anda. Recorderini memiliki mikrofon stereo X / Y yang mampu menangani 140 dB SPL, serta low-noise preamp dengan kombinasi pengunci XLR / 1/4 input, mode perekaman multiple, efek on-board, built-in metronome, chromatic tuner dan lainnya.
H4n Pro dapat merekam hingga empat imultaneous channel audio dan tingkat sampel lebih tinggi dari kualitas CD, menangkap sumber suara dalam format WAV dan MP3. Handy recorder inijuga menggunakan kartu SDHC untuk penyimpanan dan koneksi USB untuk mentransfer materi ke komputer Anda. Sepasang baterai AA standar memberi kekuatan pada perangkat dan dapat menyediakan perekaman terus menerus hingga 12 jam dalam mode Stamina (menggunakan baterai NiMH 2450 mAh).
Fitur Utama
- Mikrofon Stereo Onboard & Speaker Internal
- Input Mikrofon/Line/Instrumen XLR-1/4″ Ganda
- Overdubbing dan Perekaman 4 Saluran
- Merekam dalam WAV hingga 96 kHz
- Output Saluran / Headphone 3.5mm
- FX Bawaan untuk Mencampur Trek
- Bekerja dengan 2 baterai standard AA alkaline atau NiMH rechargeablebatteries dengan runtime hingga 6 jam (up to 10 jam pada Staminamode)
- Mendukung Kartu SDHC hingga 32 GB
- Fungsi Metronom dan Tuner
Specification
| Number of Tracks | Simultaneous Recording Tracks: 2 (stereo mode), 4 (4-channel mode), 2 (MTR mode) Simultaneous Playback Tracks: 2 (stereo mode), 4 (4-channel mode), 4 (MTR mode) |
| Recording Time | 4 GB with SDHC: Approx. 380 minutes (WAV 44.1 kHz/16-bit stereo track) Approx. 68 hours (MP3 44.1 kHz/128 kbps stereo track)* Recording times are approximations |
| Recording File Size | Maximum: 2 GB |
| Project Files | 1000/card |
| Locate Function | Hours/Minutes/Seconds/Milliseconds |
| Other Functions | Punch-in/out, Bounce, A-B repeat |
| Effects | Modules: 2 Stereo/4 Ch Mode: Lo Cut, Compressor/Limiter MTR Mode: Pre Amp module, EFX module |
| Type | 53 |
| Patches | 60 |
| Tuners | Chromatic, Guitar, Bass, Open A/D/E/G, DADGAD |
| Metronome | Sound Sources: 5 |
| Beat | Variable: 1/4 to 8/4, 6/8, unaccentuated |
| Tempo | 40.0 to 250.0 BPM |
| A/D and D/A Conversion | 24-bit x 128 oversampling |
| Recording Media | SD card (16 MB to 2 GB), SDHC card (4 to 32 GB) |
| Display | 128 x 64 dots full-dot backlit LCD |
| Data Type | WAV Format (Record/Play) Quantization: 16/24-bit Sampling Frequency: 44.1, 48, and 96 kHz MP3 Format (Recording) Bit Rate: 48, 56, 64, 80, 96, 112, 128, 160, 192, 224, 256, 320kbps, VBR Sampling Frequency: 44.1 kHz MP3 Format (Playback) Bit Rate: 48, 56, 64, 80, 96, 112, 128, 160, 192, 224, 256, 320kbps, VBR Sampling Frequency: 44.1/48 kHz |
| Inputs | |
|---|---|
| General | 1 & 2: XLR (balanced input) / 1/4 (6.3 mm) phone (unbalanced input) combo jack |
| Input Impedance | Balanced: 3 kOhms or more, pin-2 hot Unbalanced: 470 kOhms or more |
| Input Gain | Balanced: -16 to 43 dB Unbalanced: -30 to 32 dB |
| Built-In Microphone | Type: Unidirectional condenser microphone Sensitivity: -45 dB/1 Pa at 1 kHz Input gain: -16 to 51 dB Maximum SPL: 140 dB |
| External Microphones | Connection: 3.5mm Mini stereo phone jack Input impedance: 2 kOhms or more Input gain: 16 to 51 dB |
| Outputs | |
|---|---|
| Line / Phone | Line output load impedance: 10 kOhms or more Rated output level: -10 dBu Phone: 20 + 20 mW (into 32-Ohms load) |
| Speaker | 400 mW 8 Ohms |
| Phantom Power | 48 & 24 V, Off |
| USB | USB 2.0 High-Speed mass-storage class operation, audio interface operation (USB functions can be operated by USB bus power) |
| Power Requirements | 5 VDC from AC adapter (ZOOM AD-14) |
| Batteries | 2 x IEC R6 (size AA) |
| Continuous Recording Time | Stereo mode: (With built-in mics at 44.1 kHz/16-bit without headphones connected): 6 hours with alkaline batteries, 8 hours with NiMH batteries. Stamina mode: (With built-in mics at 44.1 kHz/16-bit without headphones connected): 10 hours with alkaline batteries, 12 hours with NiMH batteries. |
| Dimensions (W x D x H) | 2.9 x 6.6 x 1.5 / 73 x 167.2 x 37 mm |
| Weight | 10 oz / 294 g |
