Description
360 Spatial Sound Mapping 8K 7.2 CH A/V Receiver
Experience breathtaking 8K video and immersive 3D audio with our new 7.2-channel 8K receiver.1 Enjoy space-filling sound from your 7.2 or 5.2.2 setup with Dolby Atmos and DTS:X. Its easy to enjoy all your content with Works with SONOS, Chromecast Built-in, Apple AirPlay, and Spotify Connectall via Wi-Fi or Bluetooth.
Product Highlights:
7.2-channel A/V Receiver (165 W 6 ohms, 1 kHz, 1ch, THD 0.9%)
8K & 4K/120Hz HDMI Connectivity with HDMI 2.1 support (6-in/2-out)
Supports Dolby Atmos & DTS:X object-based sound decoding
Immersive audio with Digital Cinema Auto Calibration IX and 360 Spatial Sound Mapping
Supports todays leading HDR formats: Dolby Vision, HDR10, Hybrid Log Gamma, and IMAX Enhanced.
Works With Sonos makes it possible to integrate the STR-AN1000 with your new or already existing Sonos system
Stream your way with Bluetooth, Wi-Fi, Chromecast built-in, Spotify Connect, and Apple AirPlay.
Connects to your homes other devices with Google Assistant
Sets up easily with a graphical interface that walks you through each step
Zone 2 & Zone 3 for Flexible, multi-zone distribution capability
Center channel enhancements include Center Speaker Lift Up and Acoustic Center Sync
Control with Sony Music Center app
Compatible with Sonys SA-RS3S & SA-RS5 wireless rear speakers and SA-SW3 & SASW5 wireless subwoofers
Product Features:
8K and 4K/120 HDMI Connectivity
Enjoy the latest HDMI technology with support for 8K and 4K/120 video sources. Equipped with two 8K HDMI inputs and two outputs the STR-AN1000 is capable of delivering the most stunninng picture quality and amazing clarity.
HDMI 2.1
While enabling higher quality video output and reduced latency from input devices like game consoles, HDMI 2.1 also provides support for Auto Low Latency Mode (ALLM), Variable Refresh Rate (VRR).
Supports Dolby Vision, HDR10, and Hybrid Log Gamma, and IMAX Enhanced
Enjoy dynamic, realistic picture quality with support for the leading HDR formats, including Dolby Vision, HDR10, Hybrid Log Gamma, and IMAX Enhanced.
6 HDMI Inputs/2 Outputs
The STR-AN1000 has six HDMI inputs with two inputs supporting full 8K and 4K/120 video sources, and two HDMI outputs that also support full 8K and 4K/120 video sources.
Support For The Most Advanced Object-Based Audio Formats
With support for Dolby Atmos, Dolby Speaker Virtualization, DTS:X, and DTS Vitrual:X the STR-AN1000 delivers an object based surround sound experience.
360 Spatial Sound Mapping
Experience true immersion. Sony’s exclusive 360 Spatial Sound Mapping technology reproduces a physical sound field that can adapt to your environment and create an experience that feels like a movie theatre or concert hall.
Digital Cinema Auto Calibration IX
A new technology by Sony, Digital Cinema Auto Calibration IX precisely corrects the distance, angle, sound pressure, and frequently response of each speaker that’s connected to the STR-AN1000 to create the ideal sound field for any home theatre setup.
Hi-Res Audio and 360 Reality Audio
Enjoy music the way the artists truly intended with High-Resolution Audio for crystal clear precision or discover a new way of listening with 360 Reality Audio for a truly immersive live concert or studio session experience. With the STR-AN1000, your music comes to life like never before.
Acoustic Center Sync
Acoustic Center Sync matches the audio to your compatible BRAVIA TV.
Center Speaker Lift
Center Speaker Lift Up raises the sound from the center speaker to match what’s on the TV.
Go Wireless
Sony’s SA-RS3S and SA-RS5 wireless rear speakers and SA-SW3 and SA-SW5 wireless subwoofers (sold separately) are compatible with the STR-AN1000. Two subwoofers of the same model may be connected simultaneously to the receiver.
Easy Listening
Listen to all your favorite tracks, easily. The STR-AN1000 supports audio streaming via Bluetooth, Wi-Fi, Chromecast built-in, Spotify Connect, and Apple AirPlay.
Works with SONOS
After a simple setup, your Sony A/V receiver will tie in seamlessly to SONOS. From the SONOS app you will be able to turn on your A/V receiver, switch to the designated input source for playback, and control the volume of your A/V receiver.
Voice Assistant Compatibility
Connect to your home’s other devices, and use voice control to operate your receiver with Google Assistant.
Compatible with Sony Music Center App
Control the receivers from your mobile device for operations like source selection, zone control, sound field control, volume control, media playback, and voice assistant setup.
Roon Tested
Enjoy seamless integration with your Roon system for full access to all your music–including your digital files and streaming services–all in one place.
Updated DSEE Ultimate for Enhancing Streaming Music Quality
Using AI-based technology, DSEE Ultimate accurately upscales audio to near-high-resolution sound quality, simulating a recording studio or concert environment.
Chassis and Sub-Chassis
With the addition of a sub-chassis structure on the rear of the front panel, the rigidity of the receiver is increased. This results in a further reduction of vibration and improved sound quality overall.
Power Supply Capacitors
The newly designed power supply capacitors, developed by Sony, improve stability and achieve superior sound quality.
New Large Capacity Power Transformer
The redesigned power transformer also features a new core material and bobbin to lower distortion and improve sound quality.
Redeveloped Digital Section
The new digital section enables all signal processing to be performed on a single chip while also providing lower impedance, increased capacitance, and better stability.
New DAC Enables 32-Bit Operations
Digital PCM signal input is processed at 32-bit and converted to analog by the DAC, while DSD signal input during direct mode is natively input to the DAC and converted to an analog signal.
Improved Analog Power for DAC
The DAC analog power supply uses a low- noise power supply IC to ensure that hi-fidelity performance is achieved.
Buffer Amp for DAC
A new DAC analog output filter circuit was designed utilizing a JFET and op-amp improvement in noise floor. The phase rotation was shifted to a higher frequency, expanding the bandwidth and improving sound clarity for wide-bandwidth sources like high-resolution audio.
Sony Exclusive Pre-Amp Integrated Circuit
A Sony-exclusive integrated circuit was developed to improve all amplification functions of the STR-AN1000.
Fine Sound Resistor
The special resistance materials and structure, pure copper has been used in the electrodes to achieve high volumes of data with rich, vivid audio quality.
Product Specifications:
Interface
Input and Output Terminals –Composite Monitor Out: 1 Opt: 1 Coax.: 1 Analog Audio In: 4 Headphone Out: Yes Pre Out (Subwoofer): 2 USB Front(ver) / Rear(ver): 1/0 Ethernet Port (Power over Ethernet): 1(0)
HDMI supporting HDCP2.2 In/Out – HDMI Input supporting HDCP2.2(Front): 6(0) HDMI Output supporting HDCP2.2 : 2
Speaker Output Terminals – Front A: Yes, Front B: Yes(Common with Surround Back), Center: Yes, Surround: Yes, Surround Back: Yes, Height: Yes(Common with Surround Back), Bi-AMP: Yes(Common with Surround Back)
Auto Speaker Calibration
Calibration Features –D.C.A.C. IX, Speaker Relocation: Yes, Phantom Surround Back: Yes, Automatic Phase Matching: Yes, Calibration Mic: Stereo
Decoding Format for HDMI
Decoding Format for HDMI –DSD: Yes (Up to 2.8MHz 5.1ch), LPCM: Yes (Up to 192kHz/24 bit 7.1ch), DTS HD MA / DTS HD HR: Yes/Yes, Dolby TrueHD/Dolby Digital Plus: Yes/Yes, DTS / DTS-ES (Matrix6.1 / Discrete6.1): Yes/Yes, DTS 96/24: Yes, DTS:X: Yes, Dolby Dual Mono: Yes, Dolby Atmos: Yes
Decoding Format for USB/Network Client
Hi-Res Format – DSDIFF(DSD), DSF, WAV(LPCM), AIFF(LPCM), FLAC, ALAC
Custom Install & Control Features
Zone Audio – 2nd A: HDMI(Fixed)
IR Repeat (In/Out) – Yes(1/1)
General Features
Power Consumption –240W
GUI (Graphical User Interface) – Yes
Power Requirement – 120V 60Hz
Auto Standby – Yes
Attachment – Calibration microphone, Calibration mic stand, FM wire antenna, Remote control, R03 (size-AAA) batteries
Size & Weight
Dimensions (W x H x D) – 430x156x331mm
Weight – 9.4kg
Video Features
A/V SYNC – Yes(Variable)
4K 60p 4:4:4 Support – Yes
3D over HDMI – Yes
HDR (High Dynamic Range) – Yes (HDR10, Hybrid Log Gamma, Dolby Vision)
Audio Return Channel – Yes
BRAVIA SYNC (CEC Control) – Yes (System Audio Control, System Power Off, RC Pass Through, Language Follow, One-Touch Play)
4K Output – HDMI Video Output Capability: 8K, 4K, 1080p, 1080/24p, Deep Color (up to 36 bit), Triluminous Color (xvYCC)
HDMITM Pass Through – Yes
Audio Features
Sound Enhancement Technologies –Pure Direct, DSD Native Playback, Center Speaker Lift Up, In-Ceiling Speaker Mode
Network Connectivity
Network features – Bluetooth Receiver, Bluetooth Transmitter, Wi-Fi
Spotify Connect – Yes
Amplifier
Number of Amp. Channels – 7 CH
Power Output – Front: 165W(6ohms, 1kHz, 1ch driven THD 0.9%)
Speaker Impedance – 6ohms-16ohms
Sound Field – 2CH Stereo, Direct, Auto Format Decoding, Multi Stereo, Audio Enhancer, Headphone 2CH
Tuner Features
FM/AM – Yes/No
Preset Channel (Sirius/XM/FM/AM) – TTL30 (30/0)
