Description
GodoxTT685 Thinklite TTL Flash
With full support E-TTL / E-TTL II, including high-speed sync, and a built-in 2.4GHz radio system, theGodox TT685 Thinklite TTL Flashwill make it easy to create both simple and elaborate lighting setups. When mounted on camera, it is an effective lighting tool with a powerful guide number of 197′ at ISO 100 and 200mm, a zoom range of 20-200mm, and the ability to tilt from -7 to 90 and rotate 360. As a TTL-capable unit, the TT685 can also operate as a full wireless master or slave unit with TTL functionality.
Operation is intuitive with a rear LCD panel that shows settings. Also, the flash is equipped with a Wireless Control Port for attaching an optional remote control set and it has a 3.5mm sync port for basic wired connectivity. It runs on four AA batteries, which help provide a recycle time of 0.1-2.6 seconds.
- An integrated 2.4GHz X radio system is incorporated into the TT685 for wireless triggering. Able to be set up as a master or slave, this flash will help you create a versatile lighting setup with a range of 328′ and support for 32 channels and five groups. It can also work with an optional X series transmitter for creating more elaborate setups.
- Being compatible E-TTL / E-TTL II system, users will enjoy numerous automated flash settings and the ability to use functions such as high-speed sync.
- With a guide number of 197′ at ISO 100 and 200mm the TT685 will easily illuminate most subjects. It also features a zoom head with a range of 20-200mm and a 14mm wide-angle panel for using a variety of different lenses.
- Manual power control from 1/1 to 1/128 in 1/3 EV steps.
- The flash head can be tilted from -7 to 90 and rotated a total of 360 for controlling bounce and where the light falls on the scene.
- Optical master/slave transmission is available for working with other standard flashes.
- Using an optional FT series remote control set, users can connect to the wireless control port to gain wireless control over the flash’s power settings.
- A 3.5mm sync port is available for setting up a wired connection to a camera or trigger.
- This flash runs on four alkaline or NiMH AA batteries which help deliver about 230 full-power flashes and recycle times of 0.1-2.6 seconds.
- USB connection for installing future firmware updates.
Specifications
| Mount | Shoe |
| Guide No. | 196.85′ / 60mISO100at 200mm Position |
| Exposure Control | E-TTL / E-TTL II, Manual |
| Vari-Power | 1/1 to 1/128 |
| Bounce Head | -7 to 90 |
| Swivel Head | 360 |
| Coverage | 14 – 200 mm(Full Frame) |
| Zoom Head | Full Frame: 20 – 200 mm |
| Off-Camera Terminal | 3.5 mm |
| Recycle Time | Approximately 0.1 to 2.6 Seconds |
| Flash Duration | 1/300 to 1/20000 Second |
| Flash-Ready Indicator | Yes |
| Compensation | -3 EV to +3 EV (in 1/3 EV steps) |
| Slave Timing Modes | Instant Sync Skip Preflash |
| Wireless Operation | Method: RF Distance: Up to 328.08′ / 100m Method: Optical Pulse Distance: Up to 49.21′ / 15m Mode: Master, Slave |
| Wireless Channels | 32 |
| Wireless Groups | 5 |
| Power Source | 4 xAAAlkaline, Rechargeable NiMHBatteries |
| Dimensions (W x H x D) | 2.5 x 3.0 x 7.5″ / 64.0 x 76.0 x 190.0mm |
