Description

BenQ Home Cinema Projector

Product Features:

Full HD Cinema Enjoyment for Bright Rooms

Treat your eyes to the brilliance of Full HD 1080p visuals, with amazing detail clarity and sharpness for exceptional home cinematic experiences in well-lit environments.

Big Benefits of Short Throw

Requiring minimal distance to project big-screen images in tight spaces, short throw projection also frees up useable floor space without casting shadows onto the screen.

Low Input Lag Performance

Ultra-fast 16.7ms* low input lag conveys your sights, hearings, and thoughts into actions with zero delay. (*Input lag is 16.7ms:1080p@60Hz, 33.4ms: 1080p@60Hz)

Indulge in Immersive Sound

The 5W speaker upgraded with a wider frequency range for deep bass and soaring highs, BenQ audio-enhancing technology also provides exclusive EQ algorithms for pure clarity and sensual sound quality.

Auto Vertical Keystone

Auto vertical keystone self-adjusts for squared images, letting you easily project aligned images from various angles.

Projection Distance

1.1x zoom maximizes available space with a range of throw distances for big-screen entertainment without the hassle of complicated installation.

Product Specifications:

Display

Projection System – DLP

Resolution – 1080p (1920×1080)

Resolution Support – VGA(640 x 480) to WUXGA_RB (1920 x 1200) *RB = Reduced Blanking

Brightness (ANSI lumens) – 3000lm

Contrast Ratio (FOFO) – 10000:1

Display Color – 1.07 billion colors

Native Aspect Ratio – 16:9

Light Source – Lamp

Light Source Wattage – 240W

Light Source Life – Normal 4000 hours , Economic 10000 hours , SmartEco 10000 hour, Lampsave 15000 hours

Optical

Throw Ratio – 0.69~0.83 (100″@1.5m)

Zoom Ratio – 1.2x

Lens – F/# = 2.6 – 2.78, f = 10.2 – 12.24 mm

Keystone Adjustment – 1D, Vertical +/- 40 degrees

Projection Offset – 102.5%2.5%

Clear Image Size (Diagonal) – 60″~120″

Image Size – 30”~ 300″

Horizontal Frequency – 15K~102KHz

Vertical Scan Rate – 23~120Hz


Picture Mode – Bright/ Vivid TV/ Cinema/ Sport/ Game/ User 1/ User 2/ (3D)

Color Wheel Segment – RGBYCM

Color Wheel Speed – 2X(50Hz, 60Hz)

Rec.709 Coverage – >92%

Audio

Speaker – 5W x 1

Interface

PC (D-Sub) – 1

Monitor Out (D-Sub) – 1

HDMI – 2, HDMI-1 (1.4a),HDMI-2 (1.4a/MHL/HDCP1.4)

USB Type A – 1, USB-1 (2.0/ Power Supply)

USB Type mini B – 1 (Service)

Audio in (3.5mm Mini Jack) – 1

Audio out (3.5mm Mini Jack) – 1

RS232 (DB-9pin) – 1

IR Receiver – 2 (Front & Top)

Security Bar – 1

Special Feature

LumiExpert – Yes

Compatibility

HDTV Compatibility – 480i, 480p, 576i, 576p, 720p, 1080i, 1080p

Video Compatibility – NTSC, PAL, SECAM

3D Compatibility – Frame Sequential: Up to 720p 60hHz, Frame Packing: Up to1080p 24Hz, Side by Side: Up to 1080i/p 24Hz, Top Bottom: Up to 1080p 60Hz

Environment

Power Supply – AC 100 to 240 V, 50/60 Hz

Typical Power Consumption – 320W

Standby Power Consumption – <0.5W

Acoustic Noise (Typ./Eco.) – 33/29 Dba

Operating Temperature – 0~40

Dimension and Weight

Dimensions (W x H x D)(mm) – 296 x 120 x 224 mm

Net Weight (Kg/ lbs) – 2.7 (5.95)

Accessories (Standard)

Carton – Yes, Brown Carton

Remote Control w/ Battery – Yes (RCV013)

Power Cord (by region) – x1 (1.8m)

User Manual CD – x1 (27L)

Quick Start Guide – x1 (18L)

Warranty Card (by region) – Yes

VGA(D-sub 15pin) Cable – x1 (1.5m)

Lens cover – Yes

Battery – AAA x2

OSD

OSD Language – Arabic/ Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/ Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/ Spanish/ Swedish/ Turkish/ Thai/ Traditional Chinese(28 Languages)
