Description
AT-LPW30BKR Fully Manual Belt-Drive Turntable
The AT-LPW30BKR is a fully manual, belt-drive turntable designed to give you optimal high-fidelity audio reproduction from vinyl. The two-speed (33-1/3 and 45 RPM) turntable features an anti-resonance MDF (medium density fiberboard) plinth to limit low-frequency acoustical feedback with an aesthetically pleasing black wood veneer finish.
The turntable includes a straight aluminum tonearm with adjustable tracking force and an AT-HS4 universal “-mount headshell with an AT-VM95C Dual Moving Magnet phono cartridge. Audio-Technica has been a leader in phono cartridge design for more than 50 years, and that expertise shows in the versatile, high-performance AT-VM95C cartridge, which comes with a 0.6 mil conical stylus, but is also compatible with any VM95 Series replacement stylus, offering a wide choice of options for every budget and application.
The AT-LPW30BKR is equipped with a built-in selectable phono preamp and a detachable dual RCA output cable to enable direct connection to components with or without a dedicated phono input.
Product Features:
– Fully manual, belt-drive operation with two speeds: 33-1/3 and 45 RPM
– Adjustable dynamic anti-skate control
– Professional anti-resonance, die-cast aluminum platter with rubber mat
– AT-HS4 universal “-mount headshell and AT-VM95C Dual Moving Magnet phono cartridge with 0.6 mil conical stylus
– AT-VM95C cartridge is compatible with any VM95 Series replacement stylus, offering a wide choice of options for every budget and application
– Straight tonearm with hydraulically damped lift control and lockable rest
– Anti-resonance MDF (medium density fiberboard) plinth with black wood veneer finish
– Built-in switchable phono pre-amplifier for phono or line-level output
– AC adapter handles AC/DC conversion outside of the chassis, reducing noise in the signal chain
– Includes dual RCA (male) to dual RCA (male) stereo cable, 45 RPM adapter, rubber mat, and removable hinged dust cover
Product Specifications:
Type
Belt-drive manual turntable
Motor
DC Servo
Drive Method
Belt drive
Speed
33-1/3 RPM, 45 RPM
Turntable Platter
Die-cast aluminum
Wow and Flutter
greater than 0.15% WRMS (33 RPM) at 3 kHz
Signal-to-Noise Ratio
>60dB
Output Level
Pre-amp PHONO: 4 mV nominal at 1 kHz, 5 cm/sec | Pre-amp LINE: 200 mV nominal at 1 kHz, 5 cm/sec
Phono Pre-Amp Gain
35 dB nominal, RIAA equalized
Power Supply Requirements
100-240V AC, 50/60 Hz, 0.5 A Max
Dimensions
420.0 mm (16.53″) W x 340.0 mm (13.38″) D x 116.9 mm (4.6″) H
Weight
3.90 kg (8.60 lbs.) without dust cover
Tonearm type
Static balanced straight aluminum pipe tonearm
Effective arm length
223.6 mm
Overhang
18.6 mm
Tracking error angle
greater than 2 degrees
Applicable cartridge weight
12-17 g
Stylus pressure adjustment range
0-3 g
AC adapter
12 V, 0.5 A
Replacement Stylus
AT-VMN95C
Warranty
Audio Technica Warranty
